Required Hardware
This motor requires a L2 Certification to buy.
The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-54/2560 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. This motor requires installing a forward seal disc (54FSD) during assembly. Important: High Power RMS reload kits are not compatible with Mid Power RMS products.
The K828FJ-PS is a Plugged/Smoke motor reload. Plugged reload kits do not utilize a motor-actuated delay or ejection charge. Plugged motors must be used in conjunction with a timer, altimeter or radio-activated recovery system.
This RMS motor reload utilizes RCSs exclusive Black Max™ aerospace grade composite propellant formulation, which produces a visible black exhaust plume and a denser dark tracking smoke.
The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators and requires HAZMAT shipping via FEDEX.
Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).
Specifications:
Motor Diameter: 2.125 inches (54mm)
Casing Length: 22.79 inches (579mm)
Hardware Required: RMS-54/2560
Total Impulse: 2120 N-sec
Average Thrust: 828 newtons
Peak Thrust: 1303.7 N-sec
Thrust Duration: 2.5 seconds
Delay Time: Plugged
Propellant Weight: 1373 grams
Motor Weight: 2223 grams
