Aerotech H165R-14A Redline Rocket Motor

Aerotech H165R-14A Redline Rocket Motor
  • Click to enlarge

$34.99


Product Information
Specification

Required Hardware

This motor requires a L1 Certification to buy.

The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-29/180 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. Important: High Power RMS reload kits are not compatible with Mid Power RMS products. You will need to set the desired delay time using the 18-38mm Delay Drilling Tool (RDDT), Not Included.

This RMS motor reload utilizes RCSs exclusive Redline™ aerospace grade composite propellant formulation, which produces a visible scarlet flame. Redline™ motors burning rate lies midway between that of White Lightning™ and Blue Thunder™. Photos don’t do justice to the “laser-beam” intensity and color of Redline™…. you have to see it to appreciate it!

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators. This AeroTech motor is U.S. mailable with no hazmat fee!

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

  • Specifications:

    Motor Diameter: 1.125 inches (29mm)

    Casing Length: 7.25 inches (184mm)

    Hardware Required: RMS-29/180

    Total Impulse: 165 N-sec

    Average Thrust: 165 newtons

    Peak Thrust: 190.5 N-sec

    Thrust Duration: 1.0 seconds

    Delay Time: adjustable up to 14 seconds

    Propellant Weight: 90 grams

    Motor Weight: 202 grams

Earn Reward Points: 34

Earn Discount: $1.02

Product Code963
ManufacturerAerotech Rocketry
Stock Level14
ConditionNew
Weight0.35Lb
