Aerotech K455NW-17A Warp9-White Lightning Rocket Motor


Product Information
Specification

Drill Tool (Required)

This motor requires a L2 Certification to buy.

The AeroTech Disposable Motor System DMS is a single-use motor in kit form that is assembled by the user. All of the Aerotech DMS motors use all-disposable components. The nozzle and propellant are already installed. You will need to set the desired delay time using the Universal Delay Drilling Tool (UDDT), Not Included, and then pour in the ejection charge. The Universal Delay Drilling Tool (UDDT) is required to adjust to a shorter time delay on all DMS rocket motors.

DMS motors feature a filament-wound fiberglass casing, a glass-reinforced composite phenolic nozzle, and a molded plastic bulkhead. This “boost-sustain” motor uses a combination of AeroTech’s Warp- 9™ and White Lightning™ propellants to produce a unique thrust curve with a brilliant white flame and a moderate amount of smoke. The “boost” portion of the thrust curve generates nearly 300 pounds of thrust for about 0.5 seconds, followed by a longer “sustain” phase of about 90 pounds.

This AeroTech motor pack comes with 1 rocket motor and 1 FirstFire™ Initiator and requires HAZMAT shipping via FEDEX.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

Specifications:

Motor Diameter: 2.125 inches (54mm)

Casing Length: 25 inches (635mm)

Total Impulse: 2328 N-sec

Average Thrust: 455 newtons

Peak Thrust: 1308 N-sec

Thrust Duration: 5.1 seconds

Delay Time: adjustable up to 17 seconds

Propellant Weight: 1361 grams

Motor Weight: 2286 grams
