Aerotech L339 Warp 9 Rocket Motor


Product Information
Specification

Required Hardware and forward closure bulkhead plug (98FCBP)

This motor requires a L2 Certification to buy.

The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-98/2560 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. This motor requires installing a forward seal disc (98FSD) and a forward closure bulkhead plug (98FCBP) during assembly. Important: High Power RMS reload kits are not compatible with Mid Power RMS products.

The L339N-P is a Plugged motor reload. Plugged reload kits do not utilize a motor-actuated delay or ejection charge. Plugged motors must be used in conjunction with a timer, altimeter or radio-activated recovery system.

This RMS motor reload utilizes RCSs exclusive Warp-9™ aerospace grade composite propellant formulation, which produces a prominent yellow-orange flame studded with “mach diamonds.” Warp-9 is AeroTech’s fastest burning propellant. Originally developed for Orbital’s Pegasus® fin motors, Warp-9 is perfect when you need the highest thrust possible from a given motor size.

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators and requires HAZMAT shipping via FEDEX.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

  • Specifications:

    Motor Diameter: 3.875 inches (98mm)

    Casing Length: 10.82 inches (275mm)

    Hardware Required: RMS-98/2560

    Total Impulse: 3042.9 N-sec

    Average Thrust: 316.5 newtons

    Peak Thrust: 3042.9 N-sec

    Thrust Duration: 8.8 seconds

    Delay Time: Plugged

    Propellant Weight: 1796 grams

    Motor Weight: 3210 grams

Earn Reward Points: 255

Earn Discount: $7.65

Product Code1069
ManufacturerAerotech Rocketry
ConditionNew
Weight5Lb
