Aerotech M1340 White Lightning Rocket Motor


Product Information
Specification

This motor requires a L3 Certification to buy.

The AeroTech Disposable Motor System DMS is a single-use motor in kit form that is assembled by the user. All of the Aerotech DMS motors use all-disposable components. The nozzle is already installed. Propellant needs to be installed.

The M1340W-PS is a Plugged/Smoke motor. Plugged reload kits do not utilize a motor-actuated ejection charge. Plugged motors must be used in conjunction with a timer, altimeter or radio-activated recovery system.

DMS motors feature a filament-wound fiberglass casing, a glass-reinforced composite phenolic nozzle, a machined aluminum bulkhead with a built-in 3/8-16 thread for a matching eye bolt and RCSs exclusive White Lightning™ aerospace grade composite propellant formulation, which produces a brilliant white flame with lots of dense white smoke and a throaty roar at lift-off.

This AeroTech motor pack comes with 1 rocket motor and 1 FirstFire™ Initiator and requires HAZMAT shipping via FEDEX.

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

  • Specifications:

    Motor Diameter: 3.875 inches (98mm)

    Casing Length: 21.90 inches (557mm)

    Total Impulse: 7673 N-sec

    Average Thrust: 1340 newtons

    Peak Thrust: 1928 N-sec

    Thrust Duration: 5.7 seconds

    Delay Time: Plugged

    Propellant Weight: 4036 grams

    Motor Weight: 6998 grams

Earn Reward Points: 705

Earn Discount: $21.15

Product Code2171
ManufacturerAerotech Rocketry
ConditionNew
Weight15Lb
