CTI H87-12A Imax Rocket Motor
Hazmat will be applied during checkout
This motor requires a L1 Certification to buy.
Brandname | Pro29 168H87-12A | Manufacturer | Cesaroni Technology |
Man. Designation | 168H87-12A | CAR Designation | 168-H87-12A |
Test Date | 6/26/2009 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 29.00 x 187.00 mm (1.14 x 7.36 in) |
Loaded Weight | 205.00 g (7.18 oz) | Total Impulse | 167.90 Ns (37.78 lb/s) |
Propellant Weight | 92.70 g (3.24 oz) | Maximum Thrust | 139.20 N (31.32 lb) |
Burnout Weight | 104.00 g (3.64 oz) | Avg Thrust | 86.70 N (19.51 lb) |
Delays Tested | "12,9,7,5,3" | ISP | 184.72 s |
Samples per second | 1000 | Burntime | 1.94 s |
Notes | Imax™ |
